1. This instrument fully meets the requirements for a Class 1 colorimeter in China's JJG 595-2002 "Verification Procedure for Colorimeters and Colorimeters." 2. The QC function allows users to quickly assess color accuracy against established standards and enables rapid batch inspections.
Illumination Geometry: D/8, Specular Component Included (SCI) Light Source: Full-spectrum LED Spectral Range: 400-700 nm Spectral Interval: 10 nm Measurement Aperture: 8 mm Measurement Conditions: Illuminant D65, 10° Field of View Measurement Time: Approximately 1 second Color Spaces: CIE Lab, Luv, LCh, Yxy, CMYK, RGB, Hexadecimal, WI-98, WI-Gauz, WI-R457, WI-Hunter, YI-98, Reflectance Color Difference Formulas: E*ab, E*uv, E*94, E*cmc (2:1), E*cmc (1:1), E*00, E*cmc (1.4:1) Repeatability: Standard deviation Δe*ab within 0.03 (Measurement Conditions: Average of 30 measurements on a white plate at 3-second intervals after calibration) Inter-instrument Agreement: E*ab <= 0.4, based on average value. 12 BCRA Series II tiles Dimensions: 179mm * 64.5mm * 93mm Weight: Approximately 325g Power supply: Rechargeable lithium battery 3.7V @ 4000mAh, capable of 10,000 continuous measurements on a full charge Display: 480*320 dot IPS color screen Languages: Simplified Chinese, English Charging port: USB (Type-C) Operating temperature range: 0~45°C, relative humidity 0~85% (non-condensing) Storage temperature range: -25~55°C, relative humidity 0~85% (non-condensing)
