Gloss Meter

LS192

Consult

Features
Technical Indicators
Overall Dimension

1. The LS192 is a handheld glossmeter with a universal 60° measurement angle and a measurement range of 0-1000 GU. This instrument is widely used for measuring the surface gloss of paints, coatings, metals, ceramics, stone, and printed materials. It is extremely convenient and can be used without pressing a button. An optional QC mode allows for rapid QC. Connecting to a host computer software generates intelligent data statistics and test reports. 2. The instrument uses a D65 illuminant, and the receiver's spectral response curve conforms to the photopic vision V(λ) function, ensuring more accurate measurement of colored objects. 3. The full-range accuracy of this device meets Class 1 gloss meter standards, guaranteed to pass inspection by authoritative Chinese metrology institutions. Excellent repeatability: 0-100 GU ± 0.2 GU, 100-1000 GU ± 0.2% of reading.
Measuring Angle: 60° Measuring Spot: 9 mm * 15 mm Minimum Test Material Size: 20 mm * 10 mm Test Range: 0-1000 GU Resolution: 0.1 GU Repeatability: 0-120 GU: ± 0.2 GU 120-1000 GU: ± 0.2% Reproducibility: 0-120 GU: ± 0.5 GU 120-1000 GU: ± 0.5% Zero Error: 0.1 GU Indicated Error: 0-120 GU: ± 1.5 GU 120-1000 GU: ± 1.5% Battery Capacity: Rechargeable Li-Ion 3.7V @ 1000mAh Display: 192×64 System Language: Chinese (Simplified), English Charging Port: USB (Type-C) Data Port: USB Dimensions: 102*35* 51mm Weight: Approximately 300g Operating Temperature: 10°C to 45°C, 0% to 85% relative humidity (non-exhaust) Storage Temperature: -10°C to 60°C, 0% to 85% relative humidity (non-exhaust)
